Parts Lists
To order parts, contact your Groen Certified Service Agency. Supply the model designation, part
description, part number, quantity, and, where applicable, voltage and phase or type of gas.
A. AH/1 -20, 30, and 40 Gallon Models
ITEM
NO.
PART
NO.
DESCRIPTION
ITEM
NO.
PART
NO.
DESCRIPTION
2 47552 HANDLE
9354 SANITARY HEX NUT (FOR 2" VALVE)
3 12691 KNOB
3927 SANITARY HEX NUT (FOR 3" VALVE)
4 12733 SPACER 37 9029 VALVE HANDLE (FOR 1-1/2" VALVE)
5 61012 HINGE BAR
9029 VALVE HANDLE (FOR 2" VALVE)
6 13485 HINGE COVER
12209 VALVE HANDLE (FOR 3" VALVE)
7 2378 SPACER VENT COVER 38 9028 WING NUT (FOR 1-1/2" VALVE)
8 2986 PILOT LIGHT ASSEMBLY (115V)
9028 WING NUT (FOR 2" VALVE)
9 99156 PRESSURE GAUGE
W/1908 WING NUT (FOR 3" VALVE)
10 8453 PRESSURE LIMIT CONTROL 39 2479 BULLET FOOT (STANDARD)
11 10390 RUBBER BOOT 40 286 BURNER HEAD (PROPANE & NAT. GAS)
12 74665 WARRICK ELECTRODE 41 289 2-1/2" IPS STREET ELBOW
13 12313 THERMOSTAT 42 287 VENTURITUBE
14 12314 THERMOSTAT KNOB 43 294 3/8" IPS HEX LOCKNUT
15 6904 TOGGLE SWITCH 44 288 AIR SHUTTER
16 10412 WARRICK RELAY (115V) 45 294 3/8" IPS HEX LOCKNUT
17 576 DRAFT DIVERTER 46 280 ORIFICE (NAT GAS)
18 4035 COMBUSTION DOOR 47 281 ORIFICE (PROPANE GAS)
4002 HINGE 48 279 ORIFICE SPUD
4000 PIN 49 283 PILOT BRACKET & ORIFICE (NAT. GAS)
4001 SPRING 50 284 PILOT BRACKET & ORIFICE (PROPANE)
19 8201 INSULATION DOOR 51 63048 THERMOCOUPLE LEAD
20 4112 KNOB 52 9007 REMOVABLE STRAINER, 9" DIA, 1/4"
HOLES
21 4010 SAFETY VALVE (units built before 8/1/92) 53 9040 REMOVABLE STRAINER, 9" DIA, 1/8"
HOLES
97009 SAFETY VALVE (units built after 8/1/92) 54 9057 REMOVABLE STRAINER, 9" DIA, NO
HOLES
22 13541 WATER FILL ASSY. (units built before 55 8059 3/8" IPS X 90" UNION ELBOW
8/1/92)
96007 1/2" NPT WATER FILL ASSY. (units built 56 7439 3/8" IPS CLOSE NIPPLE
after 8/1/92)
23 10668 3/4" IPS X 90° STREET ELBOW (units built 57 8504 3/8" IPS PIPE PLUG
before 8/1/92
96905 1/2" NPT STREET ELBOW (units built after 58 338 3/4 X3/8 X 3/8" REDUCING TEE
8/1/92
24 4071 1/2" GAUGE GLASS CONNECTOR 59 8239 3/4" IPS X 3" NIPPLE
ASSEMBLY
25 8917 RUBBER GAUGE GLASS GASKET 60 8124 3/4" IPS X 90° ELBOW
26
WASHER (WITH ASSEMBLY #4071) 61 — (NOT USED)
27
HEX NUT (WITH ASSEMBLY #4071) 62 — (NOT USED)
28 8742 WATER GAUGE GLASS 63 97610 3/4" BASOTROL GAS VALVE (COMPLETE)
29 13421 1/2" CONDUIT FITTING 64 8347 3/4" IPS X 90° STREET ELBOW
30 8902 COVER FOR ITEM 29 65 8229 3/4" IPS X 4" LG NIPPLE
31 8904 GASKET FOR ITEM 29 66 8347 3/4" IPS X 90° STREET ELBOW
32 9000 1-1/2" DRAW-OFF VALVE (COMPLETE) 67 5516 3/4" IPS FEMALE UNION
9046 2" DRAW-OFF VALVE (COMPLETE) 68 5561 3/4" IPS X 7" NIPPLE
12262 3" DRAW-OFF VALVE (COMPLETE) 69 345 GAS PRESSURE REGULATOR (NAT. GAS)
33 9027 VALVE STEM (FOR 1-1/2" VALVE)
3548 GAS PRESSURE REGULATOR
(PROPANE)
9048 VALVE STEM (FOR 2" VALVE) 70 — (NOT USED)
1908 3" VALVE STEM (FOR 3" VALVE) 71 — (NOT USED)
34 9024 VALVE BONNET (FOR 1-1/2" VALVE) 72 8239 NIPPLE 3/4" IPS X 3" LG
9047 VALVE BONNET (FOR 2" VALVE) 73 8172 3/4" IPS GAS COCK
3925 VALVE BONNET (FOR 3" VALVE)
35 9034 RUBBER “O" RING (FOR 1-1/2" VALVE)
9034 RUBBER "O' RING (FOR 2" VALVE)
W/1908 RUBBER "O" RING (FOR 3" VALVE)
19
