Equipment Description (cont'd)
KETTLE CHARACTERISTICS
Firing rate,
Model Ignition
Natural
gas
Propane
gas
AH/1-20 Pilot 85,000 85,000
AH/1-40
Pilot
100,000
85,000
AH/1-60
Pilot
145,000
145,000
AH/1-80
Pilot
145,000
145,000
AH/1-100
Pilot .
145,000
145,000
AH/1E-20
Spark
85,000
85,000
AH/1E-40
Spark
100,000
85,000
AH/1E-60
Spark
145,000
145,000
AH/1E-80
Spark
145,000
145,000
AH/1E-100 Spark 145,000 145,000
Dimensions
Model
Kettle
capacity,
gallons
Jacket
capacity,
gallons
Kettle
diameter,
inches
Kettle
depth,
inches
Overall
width,
inches
Overall
front-to-
back,
Rim
height,
nches
AH/1-20 20 4-1/2 20 18 36-3/4 39 40
AH/1-40
40
7
26
22
38-1/4
45
42
AH/1-60
60
9-1/2
30
25
41
49
49
AH/1-80
80
11-1/2
32
29
42-1/2
51
55-1/2
AH/1-100
100
11-1/2
32
35
42-1/2
51
61-1/2
AH/1E-20
20
4-1/2
20
18
36-3/4
39
40
AH/1E-40
40
7
26
22
38-1/4
45
42
AH/1E-60
60
9-1/2
30
25
41
49
49
AH/1E-80
80
11-1/2
32
29
42-1/2
51
55-1/2
AH/1E-100 100 11-1/2 32 35 42-1/2 51 61-1/2
Inspection & Unpacking
The unit will arrive completely assembled, wrapped in protective plastic on a heavy skid. Immediately upon
receipt, remove all protective plastic wrap form the unit, and inspect the unit for damage. Report any shipping
damage or an incorrect shipment to the delivery agent.
Write down the model number, serial number, and installation date of your unit, and file this information for
future reference. Space for these entries is provided at the top of the Service Log in this manual.
CAUTION: SHIPPING STRAPS ARE UNDER TENSION AND CAN SNAP BACK WHEN CUT.
CAUTION: UNIT WEIGHS 440 TO 1100 LB. (200 TO 500 KG). FOR SAFE HANDLING, INSTALLER
SHOULD OBTAIN HELP AS NEEDED, OR EMPLOY APPROPRIATE MATERIALS
HANDLING EQUIPMENT (SUCH AS A FORKLIFT, DOLLY, OR PALLET JACK) TO REMOVE
THE UNIT FROM THE SKID ANDMOVEIT TO THE PLACE OF INSTALLATION.
When installation is to begin, cut the straps holding the unit on the skid, and lift the unit straight up off the
skid.
4
