Groen TDB User Manual

22 OM-TDB
PARTS LIST – TDB-20E/40E
To order parts, contact your Groen Authorized Service Agent. Supply the model designation, serial
number, part description, part number, quantity, and when applicable, voltage and phase.
Key Description Part No.
1 Water Fill Assembly 137433
2 Safety Valve 097005
3 Check Valve 096915
4 Pressure Guage 084208
5 Knob 012691
6 Hand & Ball Knob Assembly 012694
7 Kettle Body Assembly - 20 137615
Kettle Body Assembly - 20 480V 139044
Kettle Body Assembly - 40 137561
Kettle Body Assembly - 40 480V 137727
8 Sight Glass 108554
9 Knob Thermostat 002868
10
Base and Pedestal Assembly - 20 Hand Tilt 137740
Base and Pedestal Assembly - 40 Hand Tilt 137739
Base and Pedestal Assembly - 20 Crank Tilt 137636
Base and Pedestal Assembly - 40 Crank Tilt 137554
11 Light, Red 116383
12 Hand Tilt Mechanism Assembly 137741
13 Pedestal Weldment - Hand Tilt 140321
Pedestal Weldment - Crank Tilt 137625
14 Electrical Mount Assembly - 208/240V 148703
Electrical Mount Assembly - 480V 149941
15 Tilt Switch 002982
16 Contactor 148102
17 Ground Terminal 129714
18 Terminal Block 003888
19 Fuse Holder 077854
20 Fuse, 3 Amp 077853
21 Transformer - 208/240V 137441
Transformer - 480V 137694
Key Description Part No.
22 Water Level Board 122192
23 Connector 140416
24 Thermostat Kit 101542
25 Pressure Switch 096963
26 Electrode Water Level 015589
27 Element - 20 208/240V 001706
Element - 20 480V 010996
Element - 40 208/240V 011094
Element - 40 480V 011088
x Crank Tilt Mechanism Assembly 122380
29 Gear Carrier Assembly 124741
30 Worm Shaft 122374
31 Worm Gear 128001
32 Gear Sector Assembly 128028
33 Handwheel Assembly 124719
34 Key, 1/4 SG x 1” 122371
35 Bearing Back Assembly 128021
36 Roll Pin 1/4 x 1-1/4” 012614
37 Retaining Ring 1.5 124764
38 Roll Pin .25 x 1.625 128036
39 Washer, Split Lock 3/8 005618
40 Screw, 3/8-16 x 1 Hex Head 005612
41 Washer, Flat 3/8 005830
x Cover Element Housing 003141
x Stantion Cover 137618
x
Decal Operating Instructions - Hand Tilt 137803
Decal Operating Instructions - Crank Tilt 137570
x Harness, High Voltage 149945
x Harness, Low Voltage 149944
x Harness, Element 148718
x- Item not depicted/called out in drawing or photograph
