Groen TDBC-20 Operator's Manual

11 OM-TDB(C) (C,A) (CE) INTERNATIONAL
Parts List
To order parts, contact your Authorized Service Agent. Supply the model designation, serial number, part description, part number, quantity, and when applicable,
voltage and phase.
Key Description Part No.
1 WATER FILL ASSEMBLY 137433
2 SAFETY VALVE 097005
3 CHECK VALVE 096915
4 PRESSURE GAUGE 084208
5 KNOB 175095
6 HAND & BALL KNOB ASSEMBLY 012694
7 KETTLE BODY ASSEMBLY, 20 QT 175062
7a KETTLE BODY ASSEMBLY, 20 QT, 480V 175061
7b KETTLE BODY ASSEMBLY, 24 QT 175067
7c KETTLE BODY ASSEMBLY, 24 QT, 480V 175068
7d KETTLE BODY ASSEMBLY, 40 QT 175072
7e KETTLE BODY ASSEMBLY, 40 QT, 480V 175071
7f KETTLE BODY ASSEMBLY, 48 QT 175084
7g KETTLE BODY ASSEMBLY, 48 QT, 480V 175085
8 BASE & PEDESTAL ASSEMBLY - 20/24QT HAND TILT 174752
8a BASE & PEDESTAL ASSEMBLY - 40/48QT HAND TILT 175362
8b BASE & PEDESTAL ASSEMBLY - 20/24QT CRANK TILT 175358
8c BASE & PEDESTAL ASSEMBLY - 40/48QT CRANK TILT 175296
9a LIGHT, AMBER 116384
9b LIGHT, RED 116383
10 POWER SWITCH 177910
11A 2" ALUMINUM KNOB, CLASSIC CONTROL 175095
11B 2" ALUMINUM KNOB, ADVANCED & C2T 174829
12 NUT, ROTARY SHAFT SEAL(NOT SHOWN) 101145
13 SIGHT GLASS 108554
14 LIGHT MOUNT BRACKET(NOT SHOWN) 175222
15 LIGHT MOUNT SPACER(NOT SHOWN) 175221
16 HAND TILT MECHANISM ASSEMBLY 137741
17 PEDESTAL WELDMENT - HAND TILT 140321
-
PEDESTAL WELDMENT - CRANK TILT 174630
18 ELECTRICAL MOUNT ASSEMBLY(CRANK TILT) - 208/240V 175229
18a ELECTRICAL MOUNT ASSEMBLY - 480V 175579
19 ELECTRICAL MOUNT ASSEMBLY(HAND TILT) - 208/240V 175439
19a ELECTRICAL MOUNT ASSEMBLY - 480V 175440
20 TILT SWITCH 002982
21 CONTACTOR 148102
22 GROUND TERMINAL 129714
23 TERMINAL BLOCK 003888
24 FUSE HOLDER 077854
25 FUSE, 3 AMP 77853
26 TRANSFORMER, 208/240V 137441
26a TRANSFORMER, 480V 137694
Key Description Part No.
27 WATER LEVEL BOARD 122192
28 CONNECTOR 140416
29 CLASSIC CONTROL 174843
30A ADVANCED CONTROL 174837
30B C2T CONTROL 176895
31 RTD PROBE(NOT SHOWN) 175429
32 PRESSURE SWITCH 177794
33 ELECTRODE WATER LEVEL 015589
34 ELEMENT - 20/24 208/240V 001706
34a ELEMENT - 20/24 480V 010996
34b ELEMENT - 40/48 208/240V 011094
34c ELEMENT - 40/48 480V 011088
x CRANK TILT MECHANISM ASSEMBLY -
35 GEAR CARRIER ASSEMBLY 124741
36 HANDWHEEL SHAFT 122374
37 WORM GEAR 128001
38 HANDWHEEL ASSEMBLY 124719
39 KEY, 1/4 SG X 1" 122371
40 BEARING BACK ASSEMBLY 128021
41 ROLL PIN .25 X 1.25 012614
42 ROLL PIN .25 X 1.625 128036
43 PLUG PIPE 010286
44 FITTING, GREASE 90 012195
45 BRASS FITTING, 1/8 NPT 175231
46 WASHER, SPLIT LOCK 3/8 005618
47 SCREW, 3/8-16 X 1 HEX HEAD 005612
48 WASHER, FLAT 3/8 005830
49 GEAR SECTOR ASSEMBLY 128028
50 BEARING ROLLER 002790
51 RETAINING RING, 1.5" 124764
52 COVER ELEMENT HOUSING 003141
53 STATION COVER 175237
54 DECAL OPERATING INSTRUCTIONS - CLASSIC CTRL 175298
55 DECAL OPERATING INSTRUCTIONS - ADVANCED CTRL 175610
x HARNESS, HIGH VOLTAGE 149945
x HARNESS, CONTROL, TDB 175289
x HARNESS, ELEMENT 148718
x FERRITE BEAD (NOT SHOWN) 175836
x OVERLAY, C2T 176892
x CORE PROBE, TDB-20 & 24, C2T 176677
x CORE PROBE, TDB-40 & 48, C2T 176678
x BRACKET, CORE PROBE, TDB-20 & 24, C2T 176658
x BRACKET, CORE PROBE, TDB-40 & 48, C2T 176659
x BRACKET ASSEMBLY, CORE PROBE STORAGE 177091
x SOCKET, PANEL MOUNT ASSY, CORE PROBE, C2T 176925
x CAP, SOCKET, PANEL MOUNT, CORE PROBE, C2T 176927
x WIRE HARNESS, CONTROL, CORE PROBE, C2T 176920
x HARNESS, CONTROL, TDB, C2T 177262
x- Item not depicted/called out in drawing or photograph
