Ground Zero IRIDIUM SERIES User Manual

7
Specifications
Model
GZIA 1.1450DX-II
Amplifier type
Mono class D
RMS Power @ 4
Ω
CEA Standard CEA-2006-A
400 W (1% THD+N)
Max Power @ 4
Ω
500 W (10% THD+N)
RMS Power @ 2 Ω
CEA Standard CEA-2006-A
750 W (1% THD+N)
Max Power @ 2
Ω
850 W (10% THD+N)
RMS Power @ 1
Ω
CEA Standard CEA-2006-A
1250 W (1% THD+N)
Max Power
1450 W (10% THD+N)
Damping factor
> 100
Low pass filter
30 Hz – 250 Hz (12 dB/Oct)
Bass boost
0 ~ +12 dB (45 Hz)
Frequency response
10 Hz – 250 Hz
(± 1 dB)
Input sensitivity
200 mV – 6 V
(± 5%)
Bass remote

Fuse(s)
3x 40A
Dimensions
w x h x l (mm)
192 x 49 x 360
Dimensions
w x h x l (inch)
7.56 x 1.93 x 14.17
