To delete template DeletChar
Description: to delete a segment (N) of templates of Flash library started from the specified
location (or PageID);
Input Parameter: StartID + Num
Return Parameter: Confirmation code (1 byte)
Instruction code: 0cH
Command (or instruction) package format:
2 bytes
4bytes
1 byte
2 bytes
1 byte
2 bytes
2bytes
2 bytes
Header
Module
address
Package
identifier
Package
length
Instruction
code
Page
number
number of
templates to
be deleted
Checksum
0xEF01
Xxxx
01H
07H
0cH
StartID
Num
sum
Acknowledge package format:
2 bytes
4bytes
1 byte
2 bytes
1 byte
2 bytes
Header
Module
address
Package identifier
Package
length
Confirmation
code
Checksum
0xEF01
Xxxx
07H
03H
xxH
sum
Note: Confirmation code=00H: delete success;
Confirmation code=01H: error when receiving package;
Confirmation code=10H: faile to delete templates;
Confirmation code=18H: error when write FLASH
To empty finger library Empty
Description: to delete all the templates in the Flash library
Input Parameter: none
Return Parameter: Confirmation code (1 byte)
Instruction code: 0dH
Command (or instruction) package format:
2 bytes
4bytes
1 byte
2 bytes
1 byte
2 bytes
Header
Module
address
Package
identifier
Package
length
Instruction
code
Checksum
0xEF01
Xxxx
01H
03H
0dH
0011H
Acknowledge package format:
2 bytes
4bytes
1 byte
2 bytes
1 byte
2 bytes
Header
Module
address
Package
identifier
Package
length
Confirmation
code
Checksum
0xEF01
Xxxx
07H
03H
xxH
sum
Note: Confirmation code=00H: empty success;
Confirmation code=01H: error when receiving package;
Confirmation code=11H: fail to clear finger library;
Confirmation code=18H: error when write FLASH
