2 bytes
4bytes
1 byte
2 bytes
1 byte
1 bytes
1 bytes
2 bytes
Header
Module
address
Package
identifier
Package
length
Confirmation
code
Parameter
1
Parameter
2
Checksum
0xEF01
xxxx
0x07
0x0005
X
X
X
sum
Parameter 1: Step Process:
0x01: Collect image for the first time
0x02: Generate Feature for the first time
0x03: Collect image for the second time
0x04: Generate Feature for the second time
0x05: Collect image for the third time
0x06: Generate Feature for the third time
0x07: Collect image for the fourth time
0x08: Generate Feature for the fourth time
0x09: Collect image for the fifth time
0x10: Generate Feature for the fifth time
0x11: Collect image for the sixth time
0x12: Generate Feature for the sixth time
0x0D: Repeat fingerprint check
0x0E: Merge feature
0x0F: Storage template
Parameter 2: fingerprint ID
Specific Acknowledge package format:
Header
Module
address
Package
identifier
Package
length
Confirm
ation
code
Step
Fingerprint
ID
Check Sum
Note
2 Bytes
4 Bytes
1 Byte
2 Bytes
1 Byte
1 Byte
1 Byte
2 Bytes
0xEF01
XXXX
0x07
0x0005
X
01
0x00
Sum
Collect image for
the first time
0xEF01
XXXX
0x07
0x0005
X
02
0x00
Sum
Generate Feature for
the first time
0xEF01
XXXX
0x07
0x0005
X
03
0x00
Sum
Collect image for
the second time
0xEF01
XXXX
0x07
0x0005
X
04
0x00
Sum
Generate Feature for
the second time
0xEF01
XXXX
0x07
0x0005
X
05
0x00
Sum
Collect image for
the third time
0xEF01
XXXX
0x07
0x0005
X
06
0x00
Sum
Generate Feature for
the third time
0xEF01
XXXX
0x07
0x0005
X
07
0x00
Sum
Collect image for
the fourth time
0xEF01
XXXX
0x07
0x0005
X
08
0x00
Sum
Generate Feature for
the fourth time
0xEF01
XXXX
0x07
0x0005
X
09
0x00
Sum
Collect image for
