Growatt Future-H Series User Manual

6
WARNING: The current capacity of power copper connector is 250A. If 3 inverters in
parallel, it must connect other power cables.( Prepare by the user itself).
Recommended cable and ring terminal size as below.
Wire size
Lenth
Ring Terminal
Torque value
2AWG
＜530mm
D(mm)
L(mm)
2~3 Nm
6.4
39.2
4.Connecting Communication cable
One inverter Two inverters in parallel Three inverters in parallel
5.Lithium Battery Module Address Setting(Please refer to the ABM 5.5L-A1-H user
manual)
6.External Electrical Connection of Energy Storage(Please refer to the SIM 6000 ES
Plus-H user manual)
If 3 inverters
in parallel, it
must connect
other power
cables
