Growatt Future-H Series User Manual

7
Power on/off
Power on:
1. Ensure all cables are connected correctly,Please check again；
2. Press the power button of any battery module(t>1s) ,
T
he RUN/ALM and SOC lights turn on;
3. wait about 5s；
4. Press down the inverter ON/OFF button,The inverter will work.
Power off:
1. First,please turn off the electrical device at the load end of the inverter;
2. Press the inverter on/off button,turn off the inverter.
3. Press the power button of any battery module for 3 seconds and then release, the battery enters
the shutdown state and all LED lights turn off.
System Maintenance
System Power-Off
1. After the system is powered off, the case still has residual power and heat, which may cause
electric shocks or burns. Therefore, protective gloves should be worn before operating the energy
storage 5 minutes later after system powered off. Maintenance operations on energy storage
should be performed only after ensuring that all indicator lights of the energy storage are off;
2. When the system is running, the system cannot be powered off completely when only turning off
the switch of the inverter. At this time, no maintenance operation can be performed on the system.
The switch of battery must be turned off before maintenance operation can be performed;
3. Power-off operation steps of the system please see the previous chapter;
Routine Maintenance
To ensure the long-term and good operation of the energy storage system, it is recommended to
perform the routine maintenance as described in this section
Trouble Shooting(Please refer to the SIM 6000 ES Plus-H user manual or
ABM 5.5L-A1-H user manual)
Items
Methods
Maintenance interval
System
cleanliness for
inverter
 Clean the dust on the dust sponge
Once every 3 months.
Electrical
connection
 Check if any cable connection is off or loose.
 Check if any cable is damaged, and especially if
there are cuts on the sheath where the cable
contacts with the metal surface.
Half a year after first
debugging and testing,
and once every six
months to one year
thereafter.
Grounding
reliability
Check if the grounding cable is grounded reliably
Half a year after first
debugging and testing,
and once every six
months to one year
thereafter
