27
4. Insert two AC terminal block insulation partitions.
5. Finally, Lock the protective cover on the inverter frame, and finally tighten the
protective cover hole.
Wire suggestion length：
Conductor cross
section
Max. cable length
MIN
7000TL-X/X(E)
MIN
8000TL-X/(XE)
MIN
9000TL-X
MIN
10000TL-X
PENL
PE
N
L
