Growatt MIN 4200TL-X User Manual

44
lower than 60°C , restart inverter, if error
message still exists, contact Growatt.
Error: 409
Bus over voltage
Restart inverter, if problem still exist,
Contact Growatt.
Error: 411
DSP communicates with M3
abnormal
Restart inverter, if problem still exist,
update the DSP&M3 firmware；
Change DSP board or M3 board, if problem
still exist, contact Growatt.
Error: 414
EEPROM fault.
Restart inverter, if problem still exist,
Contact Growatt.
Error: 417
The data sampled by the DSP and
redundant M3 is not the same.
Restart inverter, if problem still exist,
Contact Growatt.
Error: 420
GFCI fault.
Restart inverter, if problem still exist,
change power board, or contact Growatt.

Growatt MIN 4200TL-X Specifications

General

Product color	White
Overvoltage category	CAT II
Power protection features	Over voltage, Reverse polarity, Short circuit
International Protection (IP) code	IP65
Noise level	35 dB
Product type	-
Maximum power	4200 W
Output current	19 A
Number of phases	1
Output frequency	50/60 Hz
Starting voltage	100 V
MPP voltage range	80 - 550 V
Output power capacity (max)	4.2 kVA
Input operation voltage (max)	550 V
Input operation voltage (min)	80 V
Output operation voltage (max)	280 V
Output operation voltage (min)	180 V
Total Harmonic Distortion (THD)	3 %
Wi-Fi	Yes
Display technology	OLED
Operating temperature (T-T)	-25 - 60 °C

Weight and Dimensions

Depth	160 mm
Width	375 mm
Height	350 mm
Weight	10800 g
