10
9
3.4 Storage of Inverter
3.5 The advantage of the unit
3.3 Size and weight
More detail about the type label as the chart below:
Model Name
Model Name
MIN 2500 TL-X MIN 3000 TL-X MIN 3600 TL-X
MIN 6000MIN 5000MIN 4600MIN 4200
TL-XTL-XTL-XTL-X
Max input DC voltage
Max input DC voltage
Max input DC current
Max input DC current
Start voltage
Start voltage
MPP voltage range
MPP voltage range
AC nominal voltage
AC nominal voltage
AC grid frequency
AC grid frequency
Max. apparent power
Max. apparent power
AC normal output current
AC normal output current
Power factor
Power factor
Environmental
Protection
Rating
Environmental
Protection
Rating
Operation Ambient
temperature
Operation Ambient
temperature
500V
550V
12.5A/12.5A
12.5A/12.5A
100V
100V
80V~500V
80V~550V
230V
230V
50/60 Hz
50/60 Hz
4200VA
2500VA 3000VA 3600VA
4600VA
5000VA 6000VA
18.2A
18.8A 13A 15.6A
20A 21.7A 26A
0.8leading…0.8lagging
0.8leading…0.8lagging
IP 65
IP 65
- 25...+60℃ (-13...+ 140°F)
with derating above 45°C（113°F）
- 25...+60℃ (-13...+ 140°F)
with derating above 45°C（113°F）
Model
Height (H) Width (W) Depth (D)
Weight
MIN 2500-6000 TL-X
350mm 13.8inch 375mm 14.8inch 160mm 6.3inch 10.8kg
If you want to storage the inverter in your warehouse, you should choose an appropriate
location to store the inverter.
ØThe unit must be stored in original package and desiccant must be left in the
package.
ØThe storage temperature should be always between -25℃and +60℃. And the
storage relative humidity can achieve to 100%.
ØIf there are a batch of inverters need to be stored, the maximum layers for original
carton is four.
ØAfter long term storage, local installer or service department of GROWATT should
perform a comprehensive test before installation.
ØMaximum efficiency of 98.4%
ØWide input voltage range from 80--550Vdc
ØReactive power regulate
ØIntegrated DC switch
ØMulti MPP controller
ØDSP controller
ØTouch control
ØMulti active power control mode
ØEasy installation
