Growatt MIN 7000TL-X User Manual

22
Ambient dimensions of one inverter
Ambient dimensions of series inverters
 There must be sufficient clearance between the individual inverters to ensure that
the cooling air of the adjacent inverter is not taken in.
 If necessary, increase the clearance spaces and make sure there is enough fresh air
supply to ensure sufficient cooling of the inverters.
The inverter can’t install to solarization，drench，firn location. We suggest that the
inverters should be installed at the location with some cover or protection。
Min.30cm Min.30cm Min.30cm Min.30cm
Min.30cm Min.30cm Min.30cm Min.30cm
Min.50cm Min.50cm
Min.50cm
Min.50cm
Min.50cm Min.50cm Min.50cm
Min.50cm Min.50cm Min.50cm Min.50cm
Min.30cm
