35
Information
DRM0, DRM5, DRM6, DRM7, DRM8 are available.
CAUTION
Damage to the inverter due to moisture and dust penetration
Make sure the cable gland has been tightened firmly.
If the cable gland are not mounted properly, the inverter can
be destroyed due to moisture and dust penetration. All the
warranty claim will be invalid.
6.8.1 16Pin socket pin assignment
COM Socket
Pin NO.
Assignment for inverters capable of
both charging and discharging
9
DRM 5
10
DRM 6
11
DRM 7
12
DRM 8
13
RefGen
14
Com/DRM0
15
NC
16
NC
6.8.2 Method of asserting demand response modes
Mode
Socket Asserted
by shorting pins
Requirement
DRM 0
14
13
Operate the disconnection device
DRM 5
9
13
Do not generate power
DRM 6
10
13
Do not generate at more than 50% of rated power
DRM 7
11
13
Do not generate at more than 75% of rated power
AND Sink reactive power if capabie
DRM 8
12
13
Increase power generation (subject to constraints from
other active DRMs)
