Page 41/43
Number of independent MPP
trackers/strings per MPP
tracker
1/3
Output strings from SP2000 to
inverter
3
Battery data
Battery voltage range 44V
~
58VDC
Max charging voltage 57VDC/58VDC
*2
Max charging current ≤45A
Max discharging current ≤45A
Type of battery Lead-acid battery/Lithium
battery)
Battery capacity 90~200AH
Deep of discharge 50% DOD/80% DOD
*3
daily night electricity
consumption
2~9KWH
Others:
Maximum efficiency 94.0%
Input grid voltage range（single
phase）
230Vac±15%
Operating temperature range：
0℃~+40℃
Altitude 2000m
Cooling concept Natural
Environmental Protection
Rating
IP20 (indoor used)
Noise emission (typical) ≤40dB
Certificates and approvals： CE
over voltage protection yes
Low voltage protection yes
over current protection yes
over load protection yes
Output current short
protection
yes
PV and battery reverse polarity
protection
yes
Warranty： (Five years)
Connection for PV array side H4/MC4(opt)
