Appendix
237
Appendix 1
Dimensions
Suction lift/suction pipe
TM01 9799 3300
190
570
320
4 x ø10
192
240
114
218
TM02 7856 4303
0 4 8 12 16 20 24 28 32 36 40
0
1
2
3
4
5
6
7
8
9
Suction pipe
[m]
[m]
Suction lift
