English (GB) Installation and operating instructions
Original installation and operating instructions.
CONTENTS
Page
1. Symbols used in this document
2. General description
The MQ is a compact water supply system consisting
of a pump, motor, pressure tank and controller
combined in an integral unit.
The pump starts automatically when water is
consumed in the installation and stops when the
consumption ceases. The MQ is a low-noise pump
which can be installed both indoors and outdoors.
The pump is self-priming and has a non-return valve
incorporated in the suction port. See fig. 1.
The pump features a user-friendly control panel.
The pressure tank incorporated in the pump reduces
the number of starts and stops in case of leakage in
the installation.
The MQ pump has built-in overtemperature and
dry-running protection.
2.1 Applications
Typical applications:
• Water pressure boosting in storage tanks
(maximum inlet pressure 3 bar) and
• water supply from wells (maximum suction lift
8 metres), e.g.
– in private homes
– in summer houses and weekend cottages
– on farms
– in market gardens and other large gardens.
The pump can be used for rain water and has been
approved for drinking water.
The maximum suction lift of the pump can be
determined from the diagram on page 237.
Example:
If the suction lift is 2.5 metres, the length of the
suction pipe must not exceed 24 metres.
1. Symbols used in this document
8
2. General description
8
2.1 Applications
8
2.2 Type key
9
2.3 MQ pump
10
3. Pumped liquids
10
4. Technical data
10
4.1 Operating conditions
10
4.2 Electrical data
11
4.3 Dimensions
11
4.4 Approvals
11
5. Functions
11
5.1 Control panel
11
5.2 Pump stop
13
6. Mounting and connection
13
6.1 Mounting the pump
13
6.2 Electrical connection
13
6.3 Generator or inverter
14
6.4 Start-up
14
7. Maintenance
14
7.1 Service kits
15
7.2 Start-up after a long time of inactivity
15
8. Service
15
9. Disposal
15
10. Fault finding
16
Warning
Prior to installation, read these
installation and operating
instructions. Installation and
operation must comply with local
regulations and accepted codes of
good practice.
Warning
The use of this product requires
experience with and knowledge of the
product.
Persons with reduced physical,
sensory or mental capabilities must
not use this product, unless they are
under supervision or have been
instructed in the use of the product by
a person responsible for their safety.
Children must not use or play with this
product.
Warning
If these safety instructions are not
observed, it may result in personal
injury.
