English (GB)
12
10. List of warnings
11. Technical data
1)
The start pressure (p
start
)
can be set in steps of 0.5 bar (50 kPa).
The setting is described in section 5.1 DIP switches.
2)
The stop pressure (p
stop
) is only used in systems with a pressure tank.
See section 7.3 Start/stop with 1 bar (100 kPa) differential pressure.
The technical data may be limited by the pump data. See installation and operating instructions for the pump.
Indication Warning Cause
"Warning" is permanently on. Dry running. The pump has been running without water.
"Warning" flashes once per
period.
Cycling.
The pump is cycling.
Note: Occurs only if the anti-cycling function has
been enabled. See section 8.1 Anti-cycling.
"Warning" flashes three
times per period.
Protection mode.
The pump has had too many start/stop sequences
within a short period.
Each pump start is delayed a few seconds to
protect the installation. The start delay is active
until normal operation has been re-established.
Note: The protection mode will protect the
installation when the PM Rain is set to start/stop
with 1 bar (100 kPa) differential pressure, i.e. when
DIP switch 5 is set to "ON". The protection mode
functions independently of the anti-cycling
function.
"Warning" flashes more than
three times per period.
Internal fault. Internal fault in the unit.
Data 230 V model
Supply voltage 1 x 220-240 VAC
Maximum inductive contact load 10 A
Frequency 50/60 Hz
Maximum ambient temperature 0 to 55 °C
Liquid temperature 0 to 60 °C
p
start
1)
2.5 to 6 bar (250 to 600 kPa)
p
stop
2)
p
start
+ 1 bar (100 kPa)
Q
min.
1.0 litre/min.
Time delay during stopping 10 seconds
Maximum operating pressure PN 10 / 10 bar / 1000 kPa / 1 MPa
Enclosure class IP65
Volume of internal pressure tank 0.1 litre
Dimensions See fig. 9, page 15
