English (GB)
7
Fig. 3 Connection of 1.1 kW SA-CSCR models
TM06 5332 4615
L BLKBRWGRYN
Starting
capacitor
Run
capacitor
Relay
Brown
Grey
Power supply
earth conductor
Motor earth
conductor
Black
Black
Brown
Grey
Brown
Black
