Grundfos SCALA1 Integration Guide

Grundfos Holding A/S
SCALA1 Module Integration Guide Version 1.0.1
3
• The module must contain power
supply regulation on the module
• Yes.
•
Module contains a voltage regulation
• The module must contain a
permanently attached antenna, or
contain a unique antenna
connector, and be marketed and
operated only with specific
antenna(s), per Sections 15.203,
15.204(b), 15.204(c), 15.212(a),
2.929(b)
• Yes.
• External to the shield, the Printed
Circuit Board has a “F-type” antenna,
solderconnected to the matching
network
• The module must demonstrate
compliance in a stand-alone
configuration
• Yes.
• Module is to be part of a host product.
It is listed in standalone configuration,
with only power and data (USB) supply
leads
• The module must be labelled with
its permanently affixed FCC ID
label, or use an electronic display
(See KDB Publication 784748 about
labelling requirements)
• Yes.
• Label is affixed to RF shield box
• The module must comply with all
specific rules applicable to the
transmitter including all the
conditions provided in the
integration instructions by the
grantee
• Yes.
•
• The module must comply with RF
exposure requirements
• Yes.
• Bluetooth module is Bluetooth Low
Energy (BTLE) and will not have enough
power to exceed SAR limits. It is also to
be mounted >20 cm from any
bodyparts.

Grundfos SCALA1 Specifications

General

Inlet/Outlet Size	1 inch
Weight	10 kg
Mains Frequency	50/60 Hz
Pumped liquid	Clean water
Housing Material	Composite
Pump Type	Self-priming, multistage centrifugal pump
Power Supply	1 x 230 V
Liquid Temperature Range	0°C to 45°C
Protection Class	IPX4D
System Pressure	Max. 10 bar
Approvals	CE, EAC
Installation Type	Horizontal
