Grundfos UPS15-50 N Instructions

22 23
Max. 95 % RH
UP(S), UP(S)N: IPX2/IPX4
UP(S)K: IPX2D
H
max
0.7 - 7 (m)
< 43 dB(A)
Max. 1.0 MPa
(10 bar)
Min. / Max.
0 °C / +40 °C

Grundfos UPS15-50 N Specifications

General

Material	Cast Iron
Phase	1
Model	UPS15-50N
Housing Material	Cast Iron
Impeller Material	Composite
Pump Type	Circulator
Max Flow Rate	16 GPM
Max Head	5 m
Maximum Head	5 m
Maximum Flow	16 GPM
Maximum Working Pressure	10 bar
Liquid Temperature Range	2°C to 110°C
Category	Circulator Pump
Operating Temperature Range	2°C to 110°C
Max Operating Pressure	10 bar
