GRUNDIG Service Chassis LE
≥
37“
Ersatzteilliste
Spare Parts List
LP-CHASSISMODUL LE
CHASSISBOARD LE
TV
MATERIAL-NR. / PART NO.: 275990182500
ǵ
9 / 2006
ÄNDERUNGEN VORBEHALTEN / SUBJECT TO ALTERATION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. MATERIAL-NR. BEZEICHNUNG
POS. NO. PART NUMBER DESCRIPTION
POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION
POS. NO. FIG. PART NUMBER QTY.
d©
NUR FÜR INTERNEN GEBRAUCH
FOR INTERNAL USE ONLY
275990182500 LP-CHASSISMODUL LE CHASSISBOARD LE
D 100 759551241900 DIODE CHIP IMBD4148
D 101 759551241900 DIODE CHIP IMBD4148
D 103 759880116200 DIODE BA 682
D 104 759880116200 DIODE BA 682
D 400 759551241900 DIODE CHIP IMBD4148
D 402 759551296800 BZX84C-18V SOT23 DIODE-CHIP
D 506 830938405600 SMD Z-DIODE BZX84C5V6 SOT23
D 507 830938405600 SMD Z-DIODE BZX84C5V6 SOT23
D 607 759530510400 DIODE BAV 99
D 608 759530510400 DIODE BAV 99
D 609 759880572200 DIODE BAV70
D 610 759880572200 DIODE BAV70
D 611 759880572200 DIODE BAV70
D 701 759551241900 DIODE CHIP IMBD4148
D 750 830938406200 SMD Z-DIODE BZX84C6V2
D 751 759551059700 DIODE SL 23
D 752 759551059700 DIODE SL 23
D 753 830938406200 SMD Z-DIODE BZX84C6V2
D 761 759551059700 DIODE SL 23
D 762 759551241900 DIODE CHIP IMBD4148
D 763 759551059700 DIODE SL 23
D 764 759551241900 DIODE CHIP IMBD4148
D 900 832521205400 SMD DIODE BAT54C/ BAR43C
D 901 832521205400 SMD DIODE BAT54C/ BAR43C
L 104 759550541900 SMD SPULE 1UH K0805
L 105 759550541900 SMD SPULE 1UH K0805
L 106 759550541900 SMD SPULE 1UH K0805
L 107 759550541900 SMD SPULE 1UH K0805
L 701 759550451500 SPULE 10UH R0814
L 703 759550451500 SPULE 10UH R0814
L 704 759550451500 SPULE 10UH R0814
Q 100 759551098700 TRANS BC848BLT1G
Q 101 759551098700 TRANS BC848BLT1G
Q 102 759551098700 TRANS BC848BLT1G
Q 103 759551098700 TRANS BC848BLT1G
Q 104 759551098700 TRANS BC848BLT1G
Q 300 759550973400 TRANS 2N002
Q 301 759550973400 TRANS 2N002
Q 400 759551098700 TRANS BC848BLT1G
Q 401 759551098700 TRANS BC848BLT1G
Q 402 759551098700 TRANS BC848BLT1G
Q 403 759551098700 TRANS BC848BLT1G
Q 404 759551098700 TRANS BC848BLT1G
Q 405 759551098700 TRANS BC848BLT1G
Q 407 759551098700 TRANS BC848BLT1G
Q 408 830100685700 SMD-TRANS.BC 857 C
Q 501 759551098700 TRANS BC848BLT1G
Q 502 759551098700 TRANS BC848BLT1G
Q 503 759551098700 TRANS BC848BLT1G
Q 504 759551098700 TRANS BC848BLT1G
Q 506 759551098700 TRANS BC848BLT1G
Q 600 759550973400 TRANS 2N002
Q 601 759550973400 TRANS 2N002
Q 602 759551254400 TRANS.- CHIP FDV301N (FAIRC
Q 603 759551254400 TRANS.- CHIP FDV301N (FAIRC
Q 700 759551098700 TRANS BC848BLT1G
Q 750 759551098700 TRANS BC848BLT1G
Q 901 759551098700 TRANS BC848BLT1G
Q 902 759551098700 TRANS BC848BLT1G
Q 904 759551098700 TRANS BC848BLT1G
S 506 759550974700 SCARTBUCHSE DOPPELT
SAW 100 759550458000 FILTER OFW K3958M
SAW 101 759550458000 FILTER OFW K3958M
SAW 102 759550921100 FILTER OFW K9656M
SAW 103 759550921100 FILTER OFW K9656M
TU 100 759551052100 TUNER PH UV1316T/SIGH-3 SPL
TU 101 759551052000 TUNER UV 1316/A H-4
U 100 830584988600 SMD IC TDA9886T-V3 PHI >>
U 101 830584988600 SMD IC TDA9886T-V3 PHI >>
U 200 759551251400 IC VPX3226F PMQFP10X10-44
U 300 759551251900 IC-CHIP SIL9021CTU TQFP144
U 400 759540209400 IC TDA 1308T/N1
U 401 759551257600 IC-CHIP MSP4411K-VK-D6 PMQF
U 500 759551133800 IC TEA6145CDT-VIDEO-MAT-SW
U 501 759551050900 IC PI 5V 330 W
U 502 759551252200 IC-CHIP 24LC21A-ITSNG-CMOS1
U 601 759551050700 IC 24LC21A-I/SN-CMOS18K/2.5
U 602 759550542200 SMD IC M24C08N SC2.7
U 603 759551050700 IC 24LC21A-I/SN-CMOS18K/2.5
U 604 759551251800 IC-CHIP SN74LVC1G08DBVT
U 605 759551251800 IC-CHIP SN74LVC1G08DBVT
U 700 759551251600 IC-CHIP FAN1587AMX
U 701 759551251500 IC-CHIP FAN1086M33X
U 702 759551114600 IC NCP1117DT18RK
U 703 759551060700 IC NCP1117DTARK (DPAK)
U 704 759551251600 IC-CHIP FAN1587AMX
