Grundig Digta 7 Quick Reference Guide

34
Operating
EN
x Accomplish the attachment by
(I)
pressing the recording button or by moving the slide
switch either to the “
h” or “i” position.
(II)
moving the slide switch to the “e” position.
You can also preset the attaching function for all following
recordings.
x Press the “RecMode” button.
A list of possible recording modes appears on the display.
x Use the up/down buttons to navigate to the “Append” recor-
ding mode and confirm by pressing “OK”.
x End your selection with the “Save” button.
Changing of dictation features
The dictation features of stored dictations can be adapted
subsequently.
The dictation features are only available in the Menu Mode.
x Move the slide switch to the “
e” position.
x Select the desired dictation from the list by using the up-
down navigation buttons.
x Press the “Details” button.
The menu for changing the dictation features appears on the
display. The cursor is placed on the feature chosen last.
The selected features which imply different operating pro-
cedures are opened according to the menu item selected. In
the help function (lower function button) you will find a short
description of the dictation features.
Dictation features
Menu “Details”

Grundig Digta 7 Specifications

General

Frequency range	200 - 20000 Hz
Recording modes	Quality Play (QP), Standard Play (SP)
Maximum recording time	300 h
Display type	LCD
Display diagonal	1.83 \
Display resolution	160 x 160 pixels
Output power	200 mW
Loudspeaker diameter	28 mm
Interface	USB
FM radio	No
Media types supported	Internal memory & flash card
Compatible memory cards	MMC, SD, SDHC
Battery voltage	3.7 V
Battery capacity	1000 mAh
Recording battery life	25 h
Product color	Black
Microphone sensitivity	42 dB
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-15 - 35 °C
Internal memory	2048 MB

Weight and Dimensions

Depth	22 mm
Width	52 mm
Height	130 mm
Weight	125 g
