GRUNDIG Service
4 - 9
UMS 2
Ersatzteilliste / Spare Parts List
ÄNDERUNGEN VORBEHALTEN ALTERATIONS RESERVED
BEZEICHNUNG
DESCRIPTION
SACHNUMMER
PART NUMBER
POS. NR.
POS. NO.
BEZEICHNUNG
DESCRIPTION
SACHNUMMER
PART NUMBER
POS. NR.
POS. NO.
CD PLATTE
CR 601 75954-029.01 QUARZ KERAMIK CST6,00 MHZ
D 605 75952-030.43 SI-DIODE 1 N 4148
D 606 75952-030.46 Z DIODE 3,9 V 500MW
IC 1 75954-012.19 IC TDA 1302 T
IC 2 8305-341-301 IC TDA 1301 T/N1
IC 3 75953-701.03 IC SAA 7345 GP / M5
IC 4 75953-701.75 IC TDA 7073 A / N2
IC 5 75953-701.75 IC TDA 7073 A / N2
IC 7 75953-701.04 IC TDA 1311 AT / N2
IC 9 75952-030.24 IC LM 833 N
IC 508 75954-012.21 IC GL 7805 GRLTR TO-220
IC 601 75954-029.02 IC M 3818M8-175PF
IC 602 75954-010.39 IC X 24 C 04 P EPROM
L 601 75954-010.44 SPULE 22UH +-10%
Q 162 75951-004.26 QUARZ 16,934 MHZ
Q 602 75954-029.00 QUARZ 32,768 KHZ / 15PF
R 205 S 75952-030.91 SI.-WIDERST.4,7 1/4W ERD
T 201 75952-030.39 TRANS.BC 548 B
T 202 8302-200-518 TRANS.BC 517
T 203 75952-030.41 TRANS.BC 338-25
T 204 75952-030.41 TRANS.BC 338-25
T 205 8303-272-328 TRANS.BC 328-25
T 605 75952-030.39 TRANS.BC 548 B
T 606 75952-030.41 TRANS.BC 338-25
T 607 75952-030.41 TRANS.BC 338-25
T 608 8303-272-328 TRANS.BC 328-25
T 609 8303-272-328 TRANS.BC 328-25
AUDIO PLATTE
C 232 75952-030.68 ELKO 1000UF 16V
C 403 75954-029.03 ELKO 10000 UF 20% 25V
C 410 75954-029.03 ELKO 10000 UF 20% 25V
C 416 75954-029.03 ELKO 10000 UF 20% 25V
C 417 75954-029.04 ELKO 6800 UF 20% 25V
D 401 75952-030.44 SI-DIODE IN 4002
D 402 75952-030.44 SI-DIODE IN 4002
D 403 75952-030.44 SI-DIODE IN 4002
D 404 75952-030.44 SI-DIODE IN 4002
D 405 8309-707-036 Z DIODE ZPD 36 ITT
D 406 75954-010.81 Z DIODE 5,6V 500MA
D 407 75954-029.09 DIODE BR 104
D 411 75952-030.44 SI-DIODE IN 4002
D 412 75952-030.44 SI-DIODE IN 4002
D 413 75952-030.44 SI-DIODE IN 4002
D 414 75952-030.44 SI-DIODE IN 4002
D 415 75952-030.44 SI-DIODE IN 4002
D 416 75952-030.44 SI-DIODE IN 4002
D 601 75952-030.43 SI-DIODE 1 N 4148
D 602 75952-030.43 SI-DIODE 1 N 4148
D 603 75952-030.43 SI-DIODE 1 N 4148
D 604 75952-030.43 SI-DIODE 1 N 4148
D 606 75952-030.48 Z DIODE 5,1 C D035 0,5W
D 607 75954-029.11 DIODE LED GREEN RLL3N4GD-
D 608 75954-029.11 DIODE LED GREEN RLL3N4GD-
D 609 75954-029.11 DIODE LED GREEN RLL3N4GD-
D 610 75954-029.11 DIODE LED GREEN RLL3N4GD-
DP 75954-029.13 DISPLAY FV 694G
F 401 S 8315-623-010 FS. T5AL 5X20 41571
F 402 S 8315-618-225 LOET-SI.-GR 1,25 A/T
IC 101 75954-029.05 IC SOUND PROC. M62413
IC 102 75954-029.07 IC XR-1093A
IC 103 75954-029.06 IC TDA 7370
IC 104 75954-015.66 IC NJM 4556D OP-AMP
IC 105 75954-029.20 IC 4052B DUAL
IC 401 75952-030.26 IC MC 7805 CT
IC 402 75954-015.02 IC NJM 7812 A
IC 404 75954-029.08 IC GL 7809 V. REG
R 230 S 75952-030.91 SI.-WIDERST.4,7 1/4W ERD
R 231 S 75952-030.91 SI.-WIDERST.4,7 1/4W ERD
RC 601 75954-010.41 IR EMPFAENGER
S 601-S610 75952-030.07 TAKTSCHALTER
S 611-S620 75954-015.67 TASTSCHALTER
S 621 75952-030.07 TAKTSCHALTER
T 102 75952-030.41 TRANS.BC 338-25
T 202 75952-030.41 TRANS.BC 338-25
T 401 75952-030.76 TRANS.PNP BC 640
T 402 75952-030.39 TRANS.BC 548 B
T 403 75952-030.76 TRANS.PNP BC 640
T 601 75952-030.41 TRANS.BC 338-25
T 602 8303-272-328 TRANS.BC 328-25
T 603 8303-272-328 TRANS.BC 328-25
T 604 75952-030.41 TRANS.BC 338-25
T 605 75952-030.39 TRANS.BC 548 B
VR 601 75954-029.12 POTI 100KAX2 K162FMG02Y
LAUTSTAERKE
CASS.-PLATTE
C 307 75954-015.19 ELKO 2200UF 16V
C 308 75954-015.19 ELKO 2200UF 16V
C 309 75952-023.64 ELKO 2200UF 10V
D 104 75952-030.43 SI-DIODE 1 N 4148
D 304 75952-030.46 Z-DIODE 3,9V 500MW
D 305 75954-015.38 SI-DIODE BAT42
D 306 75952-030.43 SI-DIODE 1 N 4148
D 307 75952-030.43 SI-DIODE 1 N 4148
F 124 75954-010.67 FILTER
F 224 75954-010.67 FILTER
IC 103 75954-015.30 IC UPC 1330HA SIP-9
IC 104 75954-015.29 IC CXA 1100 P
IC 105 75954-015.31 IC TA 8135P DIP 16
L 102 75954-015.22 SPULE 10MH +-10%
