Chapter 2 - Installation
Insert Phone Outputs Monaural phone jacks for left and right insert phones or patch cords.
Voltage: 1µV to 4.0 V
Output impedance: 5 ohms or less
Note: When the Single Insert Phone option is used, it must be plugged into the left
insert phone output.
R6 - Bone Vibrator (1/4 inch phone jack)
Jack for bone vibrator or gray patch cord.
Voltage: 200 µV to 5.00 V RMS
Output impedance: 5 ohms or less
R7 - Subject (1/4 inch phone jack)
Response
Handswitch Accepts plug from the cable attached to the patient’s response handswitch or
handswitch patch cord.
Pin Function Voltage Impedance
1 Shield GND 0 ohm
2 Digital GND GND 0 ohm
3
Response input +5V/GND 1K ohm/0 ohm
R8 - CD Player Power (2 pin power jack)
Jack
Provides 5 V DC for CD Player.
R9 - Dip Switch/Cal An eighth position bank of switches accessible by an authorized service representative.
Switch
R10 Speakers (5 pin Din connector) Located on rear of instrument.
Connects to left and right loudspeakers.
Pin Function Impedance
1
Left speaker (high) 1.0 ohm
2
Left GND 0 ohm
3
Right speaker (high) 1.0 ohm
4
Left speaker (low) 1.0 ohm
5
Right speaker (low) 1.0 ohm
SHLD Right GND 0 ohm
2-3
1761-0100 Rev. B
