Fury Owner’s Manual Supplement
Safety Information
Rear Tire Clearance : Full Suspension
192927 Rev 0 (11/23)
Rear Tire Clearance : Full Suspension
10 mm
To check clearance:
1. Release all the air from the rear shock.
Remove the coil spring from coil
shocks (spring coil removal should
only be done by a professional bike
mechanic). Do not disconnect or
remove the shock.
2. Compress the suspension fully with
the tire inflated to its maximum
inflation pressure.
3. At various points across the tire,
measure the distance between the tire
and the component or accessory.
4. If there is less than 10 mm of
clearance available, the component or
accessory must be adjusted or
changed until there is at least 10 mm
of clearance.
Maintain 10 mm of clearance between
rear tire, any rear rack, saddle, seat
post, frame seat tube, or any mounted
accessory.
Check following saddle or seat post
adjustments.
If you have questions maintaining tire
clearances for parts of your bike,
consult with an Authorized Dealer or
with a professional cycling mechanic.
You can be severely injured, paralyzed,
or killed in an accident if you ignore this
warning.
Applies to:
• saddles
• seat posts
• rear racks
• dropper posts
• any accessory with
possible collision with
the moving tire.
