Fury Owner’s Manual Supplement
Technical Information
Dropouts
192927 Rev 0 (11/23)
NGLI-2 NGLI-2
NGLI-2
NGLI-2
3
4
b
a
4
2
1
5
6
5
Loc 242
Loc 242
NGLI-2
NGLI-2
Dropouts
1. Seatstay
2. Chainstay
3. Axle Bolt (2X)
4. Bearing spacer (4X)
5. Bearing (4X)
6. Ring clip (2X)
a. Groove
b. Small side
Identification
