Guards/Protectors
NOTICE
Damaged, loose, missing, or incorrectly-positioned protectors can lead to frame damage.
Damage of this type is not covered by the GT Limited Warranty. Make sure all frame
protectors and guards are present, are installed correctly, and are in good condition.
Identification
10
4
3
1
8
6
11
12
7
5
2
9
1 . Left, seatstay, outer
2. Right, seatstay, inner
3. Horst link, lower
4. Right, seatstay, outer
5. Right, chainstay, outer
6. Right, chainstay, upper
7. Chain guide
8. Left chainstay, outer
9. Fender/cable guide
10. Downtube protector––
11. Right, fork bumper
12. Left, fork bumper
