Repair Procedures
OP 7. Variation kit replacement
- First remove the wire rod, to be able to remove the control lever and variation parts.
- The 5 parts are available in the variation kit.
-When putting back the components on the transmission, make sure that the both
variation levers are correctly seated, and the wire rod properly inserted.
14
Wire rod
Variation rod
Rod support
Variation levers
Control lever
