Troubleshooting
This document is our property. It can't be used, duplicated or given to third parties without our written authorization
-All preliminary operations needs to be done, to be able to complete the replacement operation.
7
TROUBLESHOOTING CHECKLIST
P.8 P.9 P.10 P.10 P.12 P.13 P.14
Customer complaints Potential failure
P/N OP 1 OP 2 OP 3 OP 4 OP 5 OP 6 OP 7
Loss of traction
Loss of power
Failure of the driven pulley driven kit GT79244
R
Failure of the driver pulley driver kit GT79398
R
Damage belt belt GT37419
P P R
Broken cam cam kit GT79246
P P R
Broken inversion kit inversion kit GT79263
P P P R
Variation controls failure variation kit GT79362
P P P P R
Internal failure transmission GT87140
Loss of panic brake Broken brake lever
brake kit GT79247
R
Loss of neutral brake function
(Loss of speed range)
Broken brake lever
R
R
Loss of neutral brake function Broken brake spring
R
Loss of brake functions Internal failure transmission GT87140
loss of bypass function
Broken bypass lever
brake kit GT79247
R
Broken plastic brake lever
R
Improper disengaging in neutral position
Driver spring failure
driver kit GT79398
R
Driver bearing failure
R
Loss of speed range
Damaged driven flanges driven kit GT79244
R
Damaged driver flanges
driver kit GT79398
R
Damaged main pulley flange
R
Damaged belt belt GT37419
P P R
Broken variation rod variation kit GT79362
P P P P R
Vibration
Damaged driven flanges driven kit GT79244
R
Damaged driver flanges driver kit GT79398
R
Broken variation rod variation kit GT79362
P P P P R
Noise
Damaged driven pulley driven kit GT79244
R
Damaged driver pulley driver kit GT79398
R
Damaged belt belt GT37419
P P R
Damaged variation rod variation kit GT79362
P P P P R
R = Replacement operation / P = Preliminary operation
