GT RT400 - Page 16

Driver kit exploded view
GT79398
This document is our property. It can't be used, duplicated or given to third parties without our written authorization
16
Ramp pin
Fixed ramp
Driver support
Cover
Driver shaft
Fixed flange
Screw x3
Screw x4
Nut
Spring
Mobile flange
Bearing
Pulley spacer x2
Bearing
Spacer
Main pulley flange
Control bushing
Bearing
