GT RT400 - Page 18

Variation kit exploded view
GT79362
This document is our property. It can't be used, duplicated or given to third parties without our written authorization
18
Brake kit exploded view
GT79247
Rod support
Variation lever x2
Variation rod
Control lever
Wire rod
Bypass lever
Roller axle
Roller
Brake lever
O-ring
Brake spring
Aluminum lever
Screw
