03170-2
2043
2043
02043-8
03184-1
03170-3
03088
99003
02043
03184-2
03088
Long
03216-R2
03088
02043-9
95001
95016
x2
QUADRI RING
03216-R1 SOFT YELLOW
03216-R2 MEDIUM (IN KIT) WHITE
03216-R3 HARD RED
03216-R4 PROGRESSIVE BLUE
SPRINGS
23
REAR
1 2 3 4 5 6
SHOCK FILLING
Fully extend the piston rod so the piston is at the bottom of the shock body.
Hold the shock upright and fill the shock body with shock oil as in the picture.
Let the oil settle and allow air bubbles to rise to the top.
Slowly move the piston up and down until no more air bubbles appear.
Add shock oil as necessary.
Pull the piston rod most of the way out of the shock bod.
Let the shock rest for 5 minutes to allow the air bubbles to scape.
CODE
CST
RC0029 400
RC0062 500
RC0030 600 (IN KIT)
RC0063 700
RC0031 800
P- ONE SHOCKS OIL
BAG 14
