Section 6 — Exploded Views and Parts Lists
Generator – Drawing No. 0G5709-A
ITEM PART NO. QTY. DESCRIPTION
1 0G5455 1 ASSEMBLY, ENGINE GH-410 PORTABLE
2 049820 9 NUT HEX LOCK M8-1.25 NY INS
3 0G1746 1 BRACKET MUFFLER
4 0D4662 1 SCREW HHTR 5/16-18 X 3/4
5 022473 20 WASHER FLAT 1/4-M6 ZINC
6 022097 6 WASHER LOCK M6-1/4
7 047411 2 SCREW HHC M6-1.0 X 16 G8.8
8 084508 2 VIBRATION MOUNT
9 022145 8 WASHER FLAT 5/16-M8 ZINC
10 081990 2 SCREW SHC M8-1.25 X 40
11 0G2397 1 ENGINE ADAPTER HOUSING
12 030205 4 SCREW FHSC 3/8-16 X 3/4
13 0G5243 1 FUEL TANK ASSY 8KW PORTABLE
14 0G5445 4 SCREW HHTT M8-1.25 X 20
15 0G5211C 1 ROTOR 8KW
16 0G5457C 1 STATOR 8KW
17 0G2398 1 BEARING CARRIER REAR
18 0G6216 1 SPACER 1/2 X 1/4 X 1
19 0G5148 4 SCREW HHC M8-1.25 X 140 G8.8
20 0F4795 2 SCREW PPHM M4-0.7 X 10
21 0G5088 1 CLAMP
22 022129 5 WASHER LOCK M8-5/16
23 075431 1 SCREW IHHC 5/16-24 X 8-1/2 G5
24 0742600174 1 GROUND WIRE BEARING CARRIER-
FRAME
25 090388 3 SCREW HHTT M6-1.0 X 12
26 0G5206 1 GROMMET WIRE SLEEVE
27 0G5002 1 COVER ALTERNATOR INLET
28 023897 6 WASHER FLAT #10 ZINC
29 022152 6 WASHER LOCK #10
30 020911 4 SCREW PPHM M5-0.8 X 30
31 0G4700 2 HANDLE PORTABLE
32 097612 2 FINGERED GRIP
33 024334 4 BOLT CARRIAGE 1/4-20 X 1
34 0G1745 1 HANDLE LEG PORTABLE LEFT SIDE
35 0G4699 2 1-3/8" RUBBER END GENERATOR FOOT
36 027529 16 NUT HEX LOCK 1/4-20 NYL INS
37 0G5011 1 RAIL TANK SUPPORT ALT. SIDE
ITEM PART NO. QTY. DESCRIPTION
38 085652 2 MOUNTS VIBRATION
39 0G5958 1 CAPACITOR MOTOR RUN 47MF 440V
40 0742600175 1 WIRE, #16 START SOL-STARTER
41 0G4797 1 DEFLECTOR TANK HEAT
42 0G2475 1 DEFLECTOR, HEAT
43 0G5442 2 SNAP BUTTON - .437" DIA. HEAD
44 0G5205 1 AXLE 5/8" DIAMETER
45 0G2355 2 WHEEL, SOLID RUBBER 10" O.D.
46 022247 2 WASHER FLAT 5/8 ZINC
47 0D4999 2 PIN COTTER 1/8 X 1-1/4 ZINC PLATED
48 0G5010 1 RAIL TANK SUPPORT MUFFLER SIDE
49 0G6039 8 BOLT CARRIAGE 1/4-20 X 1-3/4
50 0G2352 1 CRADLE PORTABLE
51 023175 3 SCREW HHC 1/4-20 X 1.75 G5
52 027028 2 NUT HEX LOCK 5/16-18 NYL INS
53 0A1658 1 WASHER LOCK SPECIAL 1/4"
54 055414 1 LUG SLDLSS #2-#8 X 17/64 CU
55 092079 1 SCREW HHTT M6-1.0 X 25
56 023258 2 SCREW HHC 5/16-18 X 3-1/4 G5
57 036682 2 SCREW HHC 1/4-20 X 3 G5
58 0G5265 1 BRACKET BATTERY HOLD DOWN
59 0G2380 1 BATTERY 12V 10Ah
60 0G5264 1 BRACKET BATTERY TRAY
61 022127 3 NUT HEX 1/4-20 STEEL
62 0G1745A 1 HANDLE LEG PORTABLE RIGHT SIDE
63 052618 2 SCREW HHC M5-0.8 X 12 G8.8
64 051716 2 NUT HEX M5-0.8 G8 CLEAR ZINC
65 0742600176 1 WIRE, STARTER SOL-BATTERY
66 0742600177 1 WIRE, BATTERY (-) TO ENGINE FRAME
67 0G6392 2 BOOT, BATTERY CABLE
68 049813 1 NUT HEX M6 X 1.0 G8 YELLOW CHROME
69 0F0710 11 RIVET POP .125 X 0.337 STEEL
70 0C3168 1 WASHER LOCK SPECIAL 5/16
71 051731 1 SCREW HHC M8-1.25 X 50 C8.8
72 096021 1 GROMMET
NOTE: All painted parts should have the following suffix at the end of the part
number. Example: 0G23520ST03.
