Guardian DCS2 User Manual

(01) Hex Bolt 5/16”18x1 (4 pcs)
(02) Lag Screw #12x1” (6 pcs)
(03) Hitch Pin (3 pcs)
(04) Flange Nut 1/4”-20 (4 pcs)
(05) Flange Nut 5/16”-18 (4 pcs)
(06) Clevis Pin Long (1 pcs)
(07) Clevis Pin Short (2pcs)
(08) Rope Knob (1 pcs)
(09) Rope (1 pcs)
(10) Washer(2 pcs)
(3)
(2)
(1)
Components Identification and Inventory
Fastener (parts in screw bag) Identification
(4)
(5)
(6) (7)
(8)
(9)
(3)
(4)
(5)
(6)
(7)
(01) Power Head
(02) Header Bracket
(03) Door Bracket
(04) Door Arm: Straight
(05) Door Arm: Curved
(06) Warning Label
(07) Rail Assembly
(08) Trolley
4
(10)
(8)
(1)
(2)

Guardian DCS2 Specifications

General

Brand	Guardian
Model	DCS2
Category	Garage Door Opener
Language	English
