Gude GS 1103 PI User Manual

15
GB
Emergency procedure
Conduct a rst-aid procedure adequate to the injury
and summon qualied medical attendance as quickly
as possible. Protect the injured person from further
harm and calm them down. For the sake of eventual
accident, inaccordance with DIN13164, a workplace
has to be ttedwith a rst-aid kit. It isessential to
replace any usedmaterial in the rst-aid kitimmedia-
tely after it has been used.
If you seek help,state the following pieces ofinfor-
mation::
1. Accident site
2. Accident type
3. Number of injured persons
4. Injury type(s)
Symbols
Read the Operating Instructions
Before carrying out any work on the machi-
ne, disconnect the plug from the socket.
Cable pulling / transport prohibited
Staying in the transportation medium
prohibited
To be kept/stored in dry conditions
Not frost-resistant
Warning against dangerous electric
voltage
Warning against automatic starting
Accessories - not included in the supply;
recommended equipment specied in the
list of accessories
1½“ IG
Baujahr: 2013
Ser.-Nr.: xxxxx-xxxx-xxxx
Artikel-Nr.: 05028
FSP 7000 S
Made in P.R. China
Just in Time, Birkichstraße 6, D-74549 Wolpertshausen
FLACHSAUGERPUMPE 7000 l/h
70x50 mm
4,1
kg
7.000 l/h
l/h
max. 8 m
max. 7 m
max.
230 V/50 Hz
IPX8
400 Watt
70 mm
item-nr: 05028
typelabels - warnings - branding - positions
CUT CONTOUR:
MANUAL: PAPER COATED 80 g/m²
WARRANTYCARD: PAPER COATED 135 g/m²
!!! all stickers are shown in original size !!!
STRUCTURE OF THE SERIAL - CURRENT PRODUCTION YEAR
CURRENT
PRODUCTION
YEAR
Attention! The current production year is part on our
typelabels. It`s strictly required to update this part of
the typelabel and insert the correct current
production year.
Güde GmbH & Co. KG
Birkichstrasse 6 • D-74549 Wolpertshausen
Baujahr: 2013
Artikelnummer: XXXXX
Seriennummer: XXXXX-XXXX-XXXX
STRUCTURE OF
THE
SERIAL
xxxxx - xxxx - xxxx
Ordernumber Shippingdate (YYMM) Counter
Don´t print!
Just for example!
Just in Time GmbH - Birkichstraße 6 - D-74549 Wolpertshausen - Deutschland
01.10.2013
PRINT ON white COLORED MATERIAL
USE STRONG PLASTIC MATERIAL, RESISTANT AGAINST DELAMINATION
PRINT ON yellow COLORED MATERIAL
USE STRONG PLASTIC MATERIAL, RESISTANT AGAINST DELAMINATION
for example
50 x 23,437 mm
1
2
3
1
2
3
35°C
>
®
made for ZEUS GmbH & Co. KG
Celler Straße 47, D-29614 Soltau
www.zeus-online.de
The logo must be proportional
an the letters Mr.
Gardener must be full
white
PRINT ON transparent COLORED MATERIAL
USE STRONG PLASTIC MATERIAL, RESISTANT AGAINST DELAMINATION
Plunge the pump into water at an angle.
Manual adjustment
Any damaged or disposed electric or
electronic devices must be delivered to
appropriate collection centres.
Protect against humidity
This side up
Safety Instructions
WARNING! Electric shock!
There is a risk of an injury caused by electric
shock!
Operation is only allowed with a safety switch
against stray current (RCD max. stray current of
30mA). Please ask your electrician.
This device is not intended for use by persons (inclu
-
ding children) with limited physical, sensory or mental
capabilities or without the necessary lack experience
or knowledge unless they are supervised by a person
who is responsible for their safety or were instructed
by that person in how to use the device.
Children should be supervised to ensure that they do
not play with the device. Always keep children and
unauthorised persons out of reach of the appliance.
Operation is only allowed with a safety switch against
stray current (RCD max. stray current of 30mA). Please
ask your electrician.
Before putting into operation, a qualied electrician must
check whether electric safety measures required are in
place. Any national regulations in this regard must be
complied with.
Electric connection to a socket.
It is necessary to make sure the connecting socket
was not near water and humidity and the plug was
protected against humidity.
Check the voltage. Technical data given on the type
label must correspond with electric network voltage.
Only use splash proof extension cables approved for
outdoor purposes.
Do not grab the feeder cable, plunge the pump, lift or
carry it while it is connected to the grid!
Check the cable and/or socket for damages before
the appliance putting into operation.
To avoid danger, a damaged mains supply pipe must
be replaced by the manufacturer. Do not execute any
repair yourself under any circumstances.
