Guide TN Series - Component Identification

6
GB CN DE FR RU
- PRODUCT COMPONENTS -
This Guide is applicable to many models of this series, and
only one model is shown in the figure.
FOCUS KNOB
VISUAL
ADJUSTMENT
VISUAL
ADJUSTMENT
PUPIL
DISTANCE
ADJUSTMENT
MENU BUTTON
CELL COVER
LOWER
BUTTON
RANGING
BUTTON
SHUTTER
BUTTON
POWER
BUTTON
UPPER
BUTTON
RANGING
MODULE
INFRARED
LENS
PUPIL
DISTANCE
ADJUSTMENT
