Guildline 9230A Series - Table 2-2: 9230 A Model Series Specifications (Continued)

Section 2
TM9230A-C1-002 November, 2021
2 November, 2021
2-2
Model
Temperature
Coefficient
7
± µΩ/Ω (ppm)
Power Coefficient
8
(± µΩ/Ω (ppm)) Size (W x L x H) Weight
92310
O
PTION
A
MBIENT
A
IR
F
LOWING
O
IL
mm inches kg lbs
9230A-10 4 2 8 0.5
114 x 356 x 85 4.5 x 14 x 3.4 1.4 3.1
9230A-15 4 2 8 0.5
114 x 356 x 85 4.5 x 14 x 3.4 1.4 3.1
9230A-15R 4 2 8 0.5
114 x 356 x 85 4.5 x 14 x 3.4 1.4 3.1
9230A-30 4 2 8 0.5
114 x 356 x 85 4.5 x 14 x 3.4 1.4 3.1
9230A-50 4 2 8 0.5
114 x 356 x 85 4.5 x 14 x 3.4 2.1 4,6
9230A-100 4 2 8 0.5
114 x 356 x 139 4.5 x 14 x 5.5 2.2 4.9
9230A-150 4 2 8 0.5
114 x 356 x 139 4.5 x 14 x 5.5 2.5 5.5
9230A-300 4 2 8 0.5
114 x 406 x 96 4.5 x 16x 3.8 5.0 11.2
9230A-500 4 3 10 0.8
114 x 406 x 96 4.5 x 16 x 3.8 5.8 12.9
9230A-1000 20 8 20 2
117 x 539 x 145 4.6 x 21.2 x 5.3 13.0 28.7
9230A-1500 25 10 30 3
117 x 530 x 145 4.6 x 17.2 x 5.3 12.8 28.1
9230A-3000 30 15 30 5
122 x 424 x 216 4.8 x 16.7 x 8.5 29.1 64
9230A-5000 30 20 35 8
122 x 399 x 216 4.8 x 15.7 x 8.5 30.9 68
92310 Option
121 x 242 x 69 4.75 x 9.5 x 2.7 1.0 2.2
Table 2-2 : 9230A Model Series Specifications (Continued)
Note 7: Temperature Coefficient must be added to the uncertainty when working at temperatures outside 23 º ± 2 ºC.
Note 8: Power coefficient must be added to the uncertainty when used as a shunt above the calibrated range of currents.
2.2 General Specifications
Environmental
Operating Temperature
10 ºC to 40 ºC
Operating Humidity
< 80 % RH non-condensing
Storage Temperature
-30 ºC to 70 ºC
Storage Humidity
< 90 % RH non-condensing
