Guildline 9230A Series - Table 3-1: Cable Size Requirements

Section 3
TM9230A-C1-002 November, 2021
2 November, 2021
3-10
Model
Test Current Range
(A)
Number of Cables in
Parallel
Minimum Size
(AWG)
9230A-10
0 to 10
1
12
9230A-15
0 to 15
1
12
9230A-15R
0 to 15
1
12
9230A-30
0 to 30
1
10
9230A-50
0 to 30
1
10
9230A-50
30 to 50
1
4
9230A-100
0 to 50
1
4
9230A-100
50 to 100
1
1
9230A-150
0 to 75
1
1
9230A-150
75 to 150
1
1/0
9230A-300
0 to 150
1
1/0
9230A-300
150 to 300
1
4/0
9230A-500
0 to 250
1
4/0
9230A-500
250 to 500
1
MCM350
9230A-1000
0 to 500
1
MCM350
9230A-1000
500 to 1000
2
MCM350
9230A-1500
0 to 750
2
MCM350
9230A-1500
750 to 1500
4
MCM350
9230A-3000
0 to 2000
4
MCM350
9230A-3000
2000 to 3000
6
MCM350
9230A-5000
0 to 3000
6
MCM350
9230A-5000
3000 to 5000
10
MCM350
Table 3-1 : Cable Size Requirements
