Guildline 9230A Series - Guildline 9230 A Series Shunt Specifications; 12-Month Performance Specifications

Section 2
TM9230A-C1-002 November, 2021
2 November, 2021
2-1
2.0 9230A SERIES PRECISION DC CURRENT SHUNT
SPECIFICATIONS
2.1 9230A Model Series 12 Month Specifications
Tables 2-1 and 2-2 show the specificatons for the 9230A series. For custom models, please consult your
calibration certificate to determine uncertainties and maximum limits.
Model
1
Nominal
Resistance Value
(Ω)
Full Rated Current
(A)
2
Initial Tolerance
3
± µΩ/Ω (ppm)
Stability
4
± µΩ/Ω (ppm)
Time Constant
(Minutes)
5
A
MBIENT
A
IR
22
TO
31
W
W
/C
OOLING
90
TO
125
W
92310
Option
Ambient
Air
9230A-10 1.0 5 10 100 10 3 6
9230A-15 0.5 7.5 15 100 10 3 6
9230A-15R
6
0.1 15 NA 400 10 3 6
9230A-30 0.1 15 30 100 10 3 6
9230A-50 0.05 25 50 100 10 3 6
9230A-100 0.01 50 100 100 10 4 8
9230A-150 0.005 75 150 100 10 4 8
9230A-300 0.001 150 300 100 10 8 16
9230A-500 0.5 m 250 500 100 10 8 16
9230A-1000 0.1 m 500 1000 250 25 15 30
9230A-1500 0.05 m 750 1500 250 25 15 30
9230A-3000
10 µ
1500 3000 500 50 20 45
9230A-5000
5 µ
2500 5000 600 70 20 45
Table 2-1 : 9230A Model Series 12 Month Specifications
Note 1: Custom values (Customer specified) of nominal resistance from 5 µΩ to 1 Ω are available by special order.
Note 2: Maximum current for natural air convection use without damage to the unit is the same as the maximum current when used with the
92310 forced convection unit.
Note 3: Defined as maximum variation of resistance value as initially adjusted at time of sale, temperature 23 ºC ± 2 ºC.
Note 4: When used as a standard resistor at 1 watt Level only.
Note 5: Typical specification defined as the time for the resistance value to settle to within 10 parts in 10
6
of the final value for any change in
applied current. The time constant is typically 1 minute for flowing oil.
Note 6: The 9230A-15R is the direct replacement for the 9230/15 version shunt. The 9230A-30 has the same resistance value as the 9230-15R
and can be used up to 30 A.
