GUSTARD H26 - Output Power Vs. Impedance Graph

-
8
-
Output power vs. impedance graph
Balanced
Single-ended
600
1600
2600
3600
4600
5600
6600
7600
8600
9600
600 500 400 300 200 150 100 75 64 50 32
Power (mW)
Headphones impedance (ohm)
H26 Balanced Headphones Output Maximum
undistorted Power (mW) VS Headphones
impedance (ohm) each channel
200
500
800
1100
1400
1700
2000
2300
600 500 400 300 200 150 100 75 64 50 32
Power (mW)
Headphones impedance (ohm)
H26 Single-ended Headphones Output
Maximum undistorted Power (mW) VS
Headphones impedance (ohm) each channel
