H.264 DVR - Rear Panel Instructions

Digital Video Recorder User Manual
13
Item Name Function
1 －/Backup
1. Decrease the value in setup
2. Enter backup mode in live
2 10+ Input number 10 and the above number together with other digital keys
3 Digital button Input digitals or choose camera
4 Enter button Confirm selection
5
Direction/Multi-screen
button
1. Direction buttons. Move cursor in setup or pan/tilt PTZ
2. Change screen display like single, 4, 9 and 16 screens
6 SEARCH Enter search mode
7 REW Rewind key;
8 FF/PTZ
1. Fast forward
2. Enter PTZ mode in live
9 STOP/ESC
1. Quit play mode
2. Exit the current interface or status
10 PLAY Enter play interface;
11 USB port
To connect external USB devices like USB flash, USB HDD for backup or
update firmware
12 +/Menu button
1. Increase the value in setup
2. Enter menu from live view
13 RECORD Record manually,
14 Indicators Working indicators of power and networks, etc
15 IR RECEIVER For remote controller
Tab 2.1 Definitions of Front Panel Buttons
2.3 Rear Panel Instructions
2.3.1 Rear Panel Interface
The rear Panel interface for 4-ch is shown as Fig 2.6:
