5) Insert wing spar into wing halves. Push
together until ends touch.
6) Feed elevator servo lead into boom
housing in wing. There is a slot already
molded to allow the connector to pass easily.
8) Insert both tail booms into the wing housing
equal distances.
7) Pull connector through opening in wing
housing. This wire can be pressed into the
same channel as the aileron servo wire.
9) Glue fiberglass wing inserts to wing using contact cement or your favorite
choice of glue.
*Note* If you plan to break down your Mini Skyhunter, run the elevator servo wire
outside of wing. Secure wire using clear tape.
10) Install M3x10 screws and nuts into the plastic tail boom anchors in the
wing. Leave loose for now.
11) Attach motor to plywood firewall with four self tapping screws.
5
