3. On the screen as shown in Figure 65, select Controller Mode, and press Enter.
Figure 65 Controller Configuration screen
4. On the screen as shown in Figure 66, select a storage controller operating mode (Table 7
describes the storage controller operating modes), and press Enter.
Figure 66 Selecting a storage controller operating mode
Table 7 Storage controller operating modes
RAID: expose RAW
All RAID functions can be used. Raw physical drives are exposed to
the system.
RAID: hide RAW
All RAID functions can be used. Raw physical drives are not exposed
to the system.
HBA
RAID functions are disabled. Raw physical drives are exposed to the
