– 11 –
Lubrication schedule
Item Lubricant Activity
1, 2, 3
Rhenus LFC 2
or
KP 2 K-30
Fill the thread flanks item 1
Grease the bearings
4 + 5 Fill with grease, 250 - 300 g each
Remedy of malfunction
Fault Cause Remedy
Spindle support is not
extractable
Spindle or gearbox
faulty
Outer or inner tube
damaged
Repair the spindle
support
Spindle support stops
lifting reaching the
ground
wrong gear shifted shift into load gear
Change gear is not
possible
gearbox faulty Repair the spindle
support
Spindle support is not
retractable
Spindle or gearbox
faulty
Outer or inner tube
damaged
Repair the spindle
support
Drop tube does not
move
Telescopic tubes
jammed
Repair the spindle
support
8. DISMOUNTING AND WASTE DISPOSAL
– Dismantling only by skilled persions
– Safety instructions have to be observed
– The disposal of the product and its components has to be according
to environmental standards.
GB
