30
4 Putting into operation
Fitting the push handle: 475
Danger of injury!
• Avoid injury due to push handle acci-
dentally falling over.
1. Engage handle fittings (1) in frame by
knocking gently.
2. Turn handle fittings (1) so that they are
positioned vertically upwards.
3. Press locking springs (3) on push
handle (2).
4. Push the push handle (2) simultane-
ously into the two handle fittings (1).
5. Engage push handle in handle fittings
by knocking gently.
Fitting the push handle: 477 / 497
Danger of injury!
• Avoid injury due to push handle acci-
dentally falling over.
NOTE
The push handle can be fitted in two dif-
ferent positions depending on the body
height of the user.
1. Turn handle fittings (1) so that they are
positioned vertically upwards.
2. Press locking springs (3) on push
handle (2).
3. Push the push handle (2) simultane-
ously into the two handle fittings (1).
4. Press the push handle into the handle
fittings until the locking springs
engage.
2
2
1
1
3
3
22
1
1
3
3
