HABCO® TECHNICAL DOCUMENT - C097584 • 10125169
© HABCO Manufacturing Inc. “HABCO®, Cassette®, Cold Space Merchandiser®” are registered trademarks of HABCO Manufacturing Inc. Domestic and International Patents. Page 2
HABCO® COMMERCIAL REFRIGERATORS
SAFETY, INSTALLATION AND INSTRUCTION MANUAL
MODELS: SE40e
IMPROPER OR UNSAFE use of this appliance other than intended by
the manufacturer, can result in death, serious bodily injury, property
damage and/or appliance damage!
Please keep this manual available for other users and owners before
WARNING
INTENDED USE
HABCO® Commercial Refrigerators are designed for the commercial
-
-
tended for use in outdoor, direct sun, damp, extreme heat and/or cold
MEANINGS OF SIGNAL WORDS AND SYMBOLS
WARNING
if ignored, could result in death or serious injury.
WARNING
if not avoided, may result in minor or moderate injury.
NOTICE
cause appliance damage or environmental harm.
Table of Contents
Subject Page
INFORMATION AND TABLE OF CONTENTS ......................2
SAFETY .............................................................................3
A. INSPECTION & UNPACKING ............................................4
B. CASTER KIT INSTALLATION (Op ..............................4
C. LOCATION ........................................................................4
D. ELECTRICAL ......................................................................4
E. START-UP .........................................................................5
F. THERMOSTAT LOCATION & ADJUSTMENT .......................5
G. LIGHTING .........................................................................5
H. DOORS .............................................................................5
Sliding Door Removal ......................................................5
Correct Door Closure Spring Orienta
........................6
Sliding Door Reinstalla
..............................................6
Sliding Door Skew Adjustment ........................................7
I. SPECIFIC PREVENTATIVE MAINTENANCE .........................7
Free’n’Clear™ Condenser Coil (SE40e) ............................7
Comba
rs .........................................................8
J. GENERAL CLEANING PROCEDURES .................................8
K. TROUBLE-SHOOTING .......................................................9
ENERGY EFFICIENCY TIPS
HABCO® Commercial Refrigerators bearing the ENERGY STAR® logo
are manufactured and designed to perform within the most stringent
energy efficiency guidelines. The following energy e
ps, how-
ever, pertain to all commercial refrigerators and should be followed for
best energy efficiency results.
1. Maintain a clean condenser coil.
2. Turn off ligh
3. Maintain clean door seals and ensure bo om door guide is
clear of debris a
4. Maintain minimum 2” rear spacing behind appliance for
adequate air-flow and heat exhange.
5. Do not install in direct vicinity of high heat sources such as
ranges, and ovens.
6. Do not install directly beneath undiffused air c
vents.
7. Read, understand and observe Safety W
in this manual as many of these points will also contribute
to energy savings and appliance efficiency.
Glossary
Term Explana
Commercial Refrigerator Appliance
Free’n’Clear™ Condenser (Coil) Circular Formed Heat Exchange Coil Mounted in Base of Cabinet
Lint-Tolerant Condenser (Coil) Heat-Exchange Coil Mounted at Front Base of Cabinet
Evaporator (Coil) Cooling Coil to Ceiling of Cabinet Interior
Compressor Refrigerant Compressing Motor Mounted in Base of Refrigerator
Condensing Chamber Compressor and Condenser Coil Enclosure at Base of Cabinet
Evaporator Housing Cooling Coil Enclosure Surrounding Evaporator Coil, Mounted to Ceiling of Cabinet Interior
Mechanically Fastened Areas Areas Requiring a Tool to Access
Trained Professional
Owner Person or Company Holding Legal Title to Appliance
Roller Panel Cover Upper Front Metal Panel Covering Top Mounted Door Rollers
