KIT 8: FRONT-RIGHT SECTION OF THE HEAD
1
3
2-1
2-1
2-4
2-4
2
2-1
8-2
4
8-1
8-3
Re-t Side Panel 2-4 by
inserting its pegs into the
corresponding holes. Do not
glue in place as it will be
temporarily removed again in kit
12. If necessary, use masking
tape to hold the part in place.
Place the Front-right Section
of the Head 8-1 on the work
surface along with Pipe 8-3.
Check the fit of the three
tabs on Pipe 8-3 in the
corresponding slots in 8-1.
When satisfied with the fit,
glue firmly in place.
Take the Lower Jaw A 2-1 and
remove the Side Panel 2-4 from
2-1 by pulling gently on it.
Fit the Washer 8-2 into
the opening shown in
Lower Jaw A 2-1.
