KIT 9: CENTRE-RIGHT SECTION OF THE HEAD
1
8-1
9-1
9-5
Lay the Centre-right Section of the Head 9-1
upside down on the work surface and note
the three raised screw sockets at one end
(circled). Take the Front-right Section of the
Head 8-1 from the previous kit. To join the
parts together, t the three sockets on part
8-1 over the raised screw sockets on part
9-1, as shown and secure in place with three
2.3x6mm screws 9-5.
