Hachette ALIEN - Attach Pipes 8-6 and 8-7 to Head Assembly; Attach Pipes 9-2 and 9-3 to Head Section

2
3
KIT 9: CENTRE-RIGHT SECTION OF THE HEAD
2
3
9-1
9-2
9-3
8-7
9-1
8-1
8-6
9-2
9-3
9-4
Turn the assembly over
and take the two Pipes
8-6 and 8-7 from the
previous kit. Test fit
Pipe 8-7 over the join
between the two parts
and when certain of a
good fit, apply a little
glue and secure firmly in
place. Repeat the same
with Pipe 8-6, fitting it as
shown in the diagram.
Study the inset picture
(left) to differentiate
between parts 9-2, 9-3
and 9-4. Note how the
underside of each part
has a slightly different
layout. When certain that
9-2 and 9-3 fit neatly
over the rectangular
blocks on 9-1, apply a
little glue and secure the
parts firmly in place.
